Simple
- Easy to use, simple to clean, excellent wash results.
- Simple two-button control.
- LCD displays wash & rinse tank temperatures plus wash cycle information.
- Colour coded display.
- Chemical Pump.
Robust
- Three wash programmes - light (2 minutes), standard (3 minutes) and intensive (5 minutes).
- Temperature Interlock guaranteeing correct rinse temperature.
- Doubled-skinned door.
- Gravity Drain.
- Optional Drain Pump.
Classeq
- Made in Britain.
- Next working day delivery available.*
- Supported by a nationwide network of technicians.
D400
A compact undercounter dishwasher
Compact, front loading and with simple two button controls for effortless, consistently clean results, the D400 is the perfect dishwasher for where space is limited.
The D400 is an easy to operate dishwasher with a 400 x 400mm basket that holds 9 full-sized plates. It features three wash cycles light (2min), standard (3min) and intensive (5min), this machine is capable of cleaning up to 270 plates per hour.
The D400 comes as standard with a gravity drain, which is suitable in instances where the machine is above the waste outlet. The optional drain pump (D400P) is essential where the drainage is either higher than the machines waste outlet, or has to be pumped to a stand pipe.
Key Features
Dimensions: 450 mm x 760 mm x 517 mm Basket Size: 400 x 400 mmHow to Buy
Complete the form and we will connect you with a reseller.
Product Downloads
Login or Register to download a brochure, manuals or technical documentation.
D400 - Technical Data at a Glance
A standard Dishwasher with a 400mm x 400mm basket size. Wash up to 270 plates an hour.
Technical Details - D400
Full technical specification of the D400. Our glossary can help you understand the technical terms, still confused just complete the contact form and one our team will be in touch.
Dimensions
Width:
450 mm
Height:
760 mm
Depth:
517 mm
Door Depth - Open:
865 mm
Basket Size:
400 x 400 mm
Rack Size:
400 x 400 mm
Clear entry height:
311 mm
Performance
Theoretical max racks per hour:
30
Plates per rack :
9
Number of wash programmes:
3
Duration of wash programmes:
2, 3 & 5 minutes
Plates per hour:
270
Wash tank element:
2 kW
Rinse tank element:
2 kW
Wash tank capacity:
9.77 Litres
Rinse tank capacity:
6.5 Litres
Rinse water consumption at 3 bar:
3 Litres
Wash tank temperature:
55 °C
Rinse tank temperature:
82 °C
Wash pump power:
0.25 kW
Hydraulic Specifications
Water supply connection:
G3/4" (3/4"Bsp)
Minimum allowed supply water pressure:
2 - 4 bar
Required water flow rate:
11 L/min
Minimum incoming water temperature:
4 °C
Maximum incoming water temperature:
55°C
Gravity drain height (from machine base):
40mm
Pumped drain height (from machine base):
540mm
Drain Size:
o40mm
Electrical Specifications
Standard Configuration
Amps Required:
13A (1 phase)
Total connected load:
2.85kW
Optional Configuration
Amps Required:
13A (3 phase)
Total Connected Load:
6.58kW
Optional Configuration
Amps Required:
30A (1 phase)
Total Connected Load:
6.58kW
Additional Info
Empty Weight:
32kgs
Packed weight:
43.2kgs
Fully loaded weight:
43.5kgs
Service:
Installation
Accessories
Plate Basket - 400x400mm
30001166
Cutlery Compartment
3602258
400 Steel Coated Stand
BWS400
400 Stainless Steel Stand
SS400-D
12 Litre Manual Softener
WS12-SK
Automatic Softener
WS-AUTO
Automatic Softener - Hot
WS-HC10
Rack Pack - 400x400mm
Pack 4
